DIT® Technology

To overcome and improve the traditional Bag In Bag Out procedure, which is used worldwide to couple drums in isolation technology applications, CSV Containment has designed and manufactured a Double Iris Interface (DIT®) system, an innovative device for drum handling, containment and automation. The DIT® system can be placed on both rigid and flexible isolators and consists of a cylindrical passage box with full-diameter opening and closing ends by means of an elastic elastomer diaphragm instead of folding doors. The double elastic barrier allows to minimize the contact surface of the drum with the internal atmosphere of the contaminated chamber and to automate the insertion and extraction operations. Furthermore, it is possible to obtain a negative or positive pressure difference between the double iris passage box and the adjacent chambers. Based on the DIT® technology, we have also created the Iris mouse hole pass through.

Drum Iris Technology Posts

Iris System: always at your side.

CSV Containment has developed the first double side iris station to allow greater versatility in the use of the universal drum loading system DIT®. Having a dual access side with the drum and a single iris system, meaning the possibility of placing the double iris for lateral loading instead of at the back of the […]

Drum Discharging Glove Box.

The drum discharging glove box is among the most representative models within the vast production of rigid isolators made by CSV Containment. Powder transfer operations are made safer by the double iris on this drum discharging glove box, which is also prepared for pneumatic transfer. The glove box is equipped with a pneumatic lifter fully […]

DIT® Plexiglass Confined Environment.

There are many reasons to handle a product in a confined environment. Being able to do it in a compact space, with total visibility, and leveraging the universality of the DIT® system adds another reason: tapping into CSV Containment’s expertise. Being experts in containment, as well as designers and producers of dedicated systems, allows us […]

From Drum Iris to Powder Pump Station.

CSV Containment Unveils a Station Tailored for Powder Pump Equipment Charging & Transfer, Offering Superior Capacity & Contained Drum Handling. Powder pumps are extensively employed in pharmaceutical and chemical industries, as well as areas like the food sector, for transporting substances from drums to reactors or other structures without compromising product integrity. Ensuring the product […]

Iris Dosing Equipment.

CSV Containment presents a manually operated iris dosing equipment as an alternative to rotary valves, ensuring control, precision, and safety. Unloading bulk solid material can be a troublesome and risky operation if not managed correctly. Let’s explore how the iris dosing equipment derived from DIT® technology can help manage this delicate phase of unloading into […]

Qualitative & Quantitative Approach to Glove Box Decontamination.

The verification phase of the effectiveness of glove box decontamination produced by CSV Containment is meticulously carried out, thanks to the experience gained by our teams in cleaning validation and monitoring the containment level according to SMEPAC standards. It involves a qualitative and quantitative verification of glove box decontamination effectiveness. The two verification procedures, SMEPAC monitoring and […]

Palladium recovery in fine chemical.

The development of efficient confinement techniques helps also the environment and the circular economy, as in the case of palladium recovery in fine chemicals. The palladium recovery phase in fine chemicals is an issue that has become central since the increasing use of noble metal-based catalysts in the production of a wide range of pharmaceuticals. […]

DIT® reactor charging: a double chamber system for high performance.

CSV Containment provides three DIT® reactor charging stations with double chamber for a new department for HPAPI production. DIT® reactor charging with double chamber for HPAPI production is the safest way to charge drums, even of different diameters, without changing any part of the equipment. The DIT® dual-chamber configuration allows for a unidirectional handling flow of drums […]

DIT® Flexible Isolators.

DIT® Flexible Isolators’ technology represents one of the most versatile solutions on the market for safe reactor charging. DIT® flexible isolators are the result of combining two experiences in which CSV Containment is achieving important results: materials processed in the “Flexilab” and patented iris technology. The materials, which are certified and produced in compliance with […]

Three-chamber dispensing isolator with DIT® system.

A three-chamber dispensing isolator needs a suitable working space in a production area, but is it possible to use it by charging drums and discharging in a bin even in rooms with low heights?  Ergonomics is crucial when working, whether it is a three-chamber dispensing isolator or a drum discharging system. CSV Containment is well […]

Rotating dryer drum charging and discharging.

Drum charging and discharging in a rotating dryer have always been critical issues. However, CSV Containment doesn’t stop at much of anything! There are several problems concerning drum charging and discharging operations in a rotating dryer, first of all because of the need to contain coupling and decoupling at any charging step. In the second place, […]

New assembly workshop.

The new CSV Containment assembly workshop is a sign of quality for whoever wants excellence products made of selected raw materials, carefully manufactured and even tailor made. CSV Life Science Group, after years of work and experience in the Pharma world, has decided to start a new assembly workshop for some of its products, given the […]

Fully automated contained Drum Handling system with Lump Breaker.

Lump Breaker or granulator: the solution for break up larger agglomerates improving the flow characteristics of dry materials. After an extended storage, dry bulk materials may become compressed. Therefore, a lump breaker for de-agglomeration operations is required. Exposure to moisture can also form hard lumps that require more to tease apart. So, a lump breaker installed […]

Drum Iris Pneumatic Reactor Charging Isolator.

Drum Iris Pneumatic Reactor Charging Isolator has been built to create a universal, small, smart, light and movable station to contain reactor charging by drums via dedicated flange, manway or via Vacuum transfer systems. Drum Iris (double) interface has been challenged to verify its containment performances. The test protocol has been performed according to Standard […]

Drum Iris Vacuum Transfer Station

Vacuum Transfer by Drum Iris Technology This Vacuum Transfer station is designed to help operators safely transfer materials out of drums. The pneumatic lifter allows inverting drums to remove the contents with few operator interaction. The hopper geometry on the bottom is studied to let the powder flow down to the suitable rotary valve. By […]

Big Bag Discharging via IRIS Docking

Big Bag Discharging via IRIS Docking with integrated Cleaning in Place. This new Drum Iris Technology device includes a few innovations and has been developed to meet No Contamination/Exposition requirements and in the meanwhile the easiest and fastest Big Bag interfacing and Big Bag discharging operation. Main features: A Top Iris allows to: big bag […]

Drum Iris Two Movements Reactor Charging Station

This special reactor charging station can work horizontally or rotate completely by means of an automatic cycle. Drum Iris Two Movements Reactor Charging station features: Made of one single equipment that is the merge of the drum sliding lifter and the tilting charging station, equipped with an automatic double iris drum pass box Movable Based on Drum […]

CSV Containment IDB Isolator

CSV Containment Iris Deblistering Isolator This isolator machine includes many innovations and has been developed to guarantee ever-increasing quality for CSV customers. Features: Tablets to be deblistered transfer in by DOUBLE IRIS PASS BOX; Product bag out via Continuous Liner Negative Pressure Control; -50Pa within 14 sec SMEPAC containment performance: 44 Nanograms/m3 Plug and Play configuration Watch the video! CSV Containmentis present […]

Drum Reactor Charging DRC XS

CSV Containment is proud to present its new Drum Reactor Charging DRC XS!   Drum Reactor Charging DRC XS is: Made of one single equipment that is the merge of the drum sliding lifter and the charging station, equipped with a double iris drum pass box Movable Telescopic version avalaible Based on Drum Iris Technology using a double […]

Drum Reactor Charging DRC XS Video

Watch the video of the new Drum Reactor Charging DRC XS! Made of one single equipment that is the merge of the drum sliding lifter and the charging station, equipped with a double iris drum pass box. CSV Containment is present in the pharmaceutical market and is focused on providing engineering, construction and validation solutions for the LifeScience world. […]

Double Chamber Reactor Charging Station with double Iris Drum pass box

Double Iris for double Chamber! Highly Potent Active Pharmaceutical Ingredients (HPAPI) Reactor Charging. This new Reactor Charging Station is equipped with a double Iris Drum pass box made by CSV Containment. The Drum Iris Technology is an innovative solution, created and patented by CSV Life Science, that has obtained important results confirming its performance and […]

CSV Containment – Iris docking Big Bag Charging

CSV Containment – Iris docking Big Bag Charging System for charging Big Bag applied to industrial environments which allows the coupling of the neck in a confined space and without exposure to the product. The parts in contact with the product can be made of AISI 316L or anti-acid material such as hastelloy or coated steel. […]

CSV Containment – Powder processing dispensing isolator

CSV Containment – Powder processing dispensing isolator Powder processing dispensing isolator for the safe handling of hazardous substances. CSV continues to improve and specialize to create increasingly efficient and complete containment systems. Our systems can be customized over time thanks to the clamped connections and modularity that allow you to add additional accessories and tools or […]
